Coaxial speaker, 2 ways, plastic material with IP65W protection, UV protection.
Click on the type below for more details and variants
| System | 8 Ω |
|---|---|
| Power Wrms |
80 |
| Impedance ohm |
8 Ω |
| Frequency range Hz | 70÷20000 |
| SPL 1W/1m |
86dB |
| SPL MAX |
105dB |
| Coverage angle degrees |
95°x95° |
| Weight kg |
10,3 |
| Dimensions mm |
H1020 x W115 x D160mm |
| System | 8 Ω |
|---|---|
| Power Wrms |
200 |
| Impedance ohm |
8 Ω |
| Frequency range Hz | 90÷18000 |
| SPL 1W/1m |
96dB |
| SPL MAX |
119dB |
| Coverage angle degrees |
80°x80° |
| Weight kg |
10,3 |
| Dimensions mm |
H1020 x W115 x D160mm |
| System | 100V |
|---|---|
| Power Wrms |
200-180-120-60-40 |
| Impedance ohm |
50-55,5-83,3-166,6-250 Ω |
| Frequency range Hz | 70÷20000 |
| SPL 1W/1m |
92dB |
| SPL MAX |
115dB |
| Coverage angle degrees |
110° |
| Weight kg |
7.5kg |
| Dimensions mm |
H1020 x W115 x D160mm |
| System | 100V |
|---|---|
| Power Wrms |
46-24-12 |
| Impedance ohm |
217-416-833 Ω |
| Frequency range Hz | 60÷20000 |
| SPL 1W/1m |
86dB |
| SPL MAX |
103dB |
| Coverage angle degrees |
90°x90° |
| Weight kg |
6,9 kg |
| Dimensions mm |
H1020 x W115 x D160mm |
Coaxial speaker, 2 ways, plastic material with IP65W protection, UV protection.
Nominal impedance: 8 ohm, and power selection 80W RMS.
Speakers: n.1 treated woofer 8 inches, n.1 HF driver.
Complete with 2 clamps PG11 type, and stainless steel covering grid with 3 protective films.
Black or white color cabinet, with 2 holes for 8 MA screws for U shape stainless steel bracket.
